EP Drape – Large
Tested in accordance with ASTM standards, ScatterGuard EP patient drapes provide excellent protection for fluoro-lab and operating suite personnel during interventional procedures. These drapes are placed over the patient, so you benefit from added protection without the added weight! They are highly absorbent, sterile, disposable through normal waste procedures, conform to the patient’s body, and feature 3M adhesive backing to prevent slippage.
Minimum Order: 10 drapes (1 box)
- Dimensions: 16″ x 16″
- Fenestration: 5.75″ x 3″ Center Scoop Fenestration
- Core Material: Prolite Max
- Protection Options: 0.25mm LE
- Shelf Life: Sterile – 3 years after manufacture date
- Quantity: 10 drapes per box
- Fabric: ActiV – highly absorbent
- CE Marked: Yes (only applies to 0.25mm LE)
- Certifications: Certified to ASTM F2547-18 standards.
IEC 61331-1:2014 certified drapes available upon request.
- For Use During: Bi-ventricular pacemaker implants, ICS procedures and bi-ventricular pacing
|Lead Equivalence||Attenuation @ 90kV|
|Fabric||Weight||Absorbency Rate||Absorbency Capacity|
|ActiV Absorbent||120 gsm||1.2 sec/ml||620%|
|Leading Competitor 2||130 gsm||2.5 sec/ml||600%|
|Leading Competitor 1||109 gsm||1.9 sec/ml||526%|
Compliance Requirements: ASTM F2547-18
Biocompatibility Compliance: ISO 10993, ASTM F719 and ASTM F720
Disposal: Scatterguard Drapes should be disposed of through normal waste procedures in accordance with local laws and regulations. The material should not be disposed of by incineration and use of self-contained breathing apparatus is recommended if the sheeting is ignited by fire.
Expiration: This is a sterilized product and expiration is set at 3 years from manufactured date per FDA requirement. This indication may be found on the label on the original external packaging and indicates the period of time during which the device, sterilized with Gamma Radiation, may be used as long as it has been stored properly in suitable conditions and has intact packaging.
