Single Sided Table Drape

Table Drapes provide protection against scatter radiation for your lower body and are specially designed to not obstruct positioning of the C-arm. The single sided table drape uses Velcro to adhere to the side of your imaging table and allows for easy cleaning and adjustability. Each drape panel is 6″ wide.

Table drapes are made standard with Lead Core Material at 0.50mm LE thickness.

For custom sizing, core material, or thickness please contact us.

  • Total

Product Information


Features

  • Multi-panel design allows for easy maneuverability around imaging table
  • Large Velcro strip provided – affixes to operating table
  • Also available as a Double-Sided Table Drape
Drape Features: Made in the USA

Made in the USA

Drape Features: custom sizing available

Fully Customizable

Barrier Features: No CE certification

Not CE Certified


Single-sided Table Drape Characteristics
  • Barrier Type: Stationary – lower body protection
  • Protection (thickness): 0.50mm LE
  • Core Material: Standard Lead
  • CE Certified: No
  • Fabric Options: Nylons and Ripstop
  • Customization Options: Limited Online, Contact us for more options

Barrier Attenuation
CORE MATERIAL LEAD EQUIVALENCE 70kVp 90kVp 110kVp 130kVp
Standard Lead 0.50mm LE 98.8% 95.7% 94.1% 93.1%

Compliance Standards

Intended Use: Lead Barriers are used by healthcare professionals as a solution to protect them from the harmful effects of x-ray radiation during medical & other procedures requiring the use of x-ray/fluoroscopy. Barriers are usually used in combination with other radiation safety products (such as lead garments) to provide complete protection from x-ray.

EN 61331-1:2014: (EU) Protective devices against diagnostic Medical X-ray radiation. (Determination of attenuation properties of material)
EN 61331-3:2014: (EU) Protective devices against diagnostic medical X-radiation Part 3: Protective clothing, Eyewear and Protective Patient shields.
ASTM 2547-18: (USA) Standard test method for determining the attenuation properties in a primary x-ray beam of materials used against radiation.


Maintaining Your Table Drape
Storage: Keep Table Drapes out of direct sunlight and prolonged exposure to extreme heat. Store at 70-80°F (21-27°C). Temperature limits are approximately 60-100°F (16-38°C). Table Drapes are intended to remain on the operating table they are affixed to. If removed, please hang Table Drapes on an appropriate rack (See Valet Rack ) or lay flat on the ground or a countertop if rack is not available.

Maintenance: Table Drape fabrics can be cleaned by hand using mild soap diluted with room temperature water. Clorox hydrogen peroxide in diluted form is permissible. PDI Sani-Cloth® AF3 Germicidal Disposable Wipes are approved for use on Protech aprons.

Disposal: Users must dispose of Table Drapes by complying with local, state and federal (or international) regulations where applicable.

Warranty: Protech’s Lead Table Drapes are warranted to be free of defects in materials and workmanship to the original purchaser for one year. If a defect appears, please contact us or an authorized reseller to begin the RMA process. You can also go directly to our Return Merchandise Form and begin the return process.

The warranty is void when the product has been tampered with, when repairs or attempted repairs have been made by unauthorized persons, or when the item has been subject to misuse, abuse or damage in transit. For more information on Returns, Repairs and Warranty, please visit our Shipping, Warranty and Returns page.
